10000 Litre Diesel Storage Tank with Sightglass

Looking to store Diesel for future re-use. Boasting a sight glass to help manage diesel levels, this diesel tank is your ideal diesel storage solution.

The 10,000 Litre Diesel Tank is well suited to rural, commercial and industrial use.

Dimensions

VIC – 2600mm D x 2235mm H – Inlet Height 2000mm

NSW – 2630mm D x 2100mm H – Inlet Height 2020mm

QLD – 2620mm D x 2100mm H – Inlet Height 1975mm

Colour

• Colour – Black

Features

Inlet

• 1 x Camlock 2 Inch Male Thread Type F  63mm – Aluminum
• 1 x Camlock 2 Inch Dust Cover 63mm Poly
• 1 x 50mm Brass Lever Ball Valve – Lead Free
• 1 x Pipe Riser Assembly – 2 Inch 63mm One Piece Welded
• 1 x Adaptor PE 63mm BSP

Outlet

• 1 x Adaptor Male PE 63mm BSP – short radius
• 1 x Brass Ball Valve 50mm
• 1 x Camlock 2 Inch Male Thread Type F  63mm – Aluminum
• 1 x Camlock 2 Inch Dust Cover 63mm Poly
• 1 x Tank Guard 150mm x 300mm x 150mm

Sight glass Kit

• 2 x 25mm Male Adaptor PE
• 1 x Elbow PP 20mm Male/Female Valve
• 1 x Banjo Ball Valve 20mm BSP
• 1 x 25mm Adaptor BSP Male
• 1 x PVC Tube to suit
• 1 x Sighglass Guard

Vent

• 1 x Shepherd Hook Vent 63mm – 50mm ID

PUMP PROVISION SET UP – optional Extra

These diesel tanks come with optional additions – If you wish to add your own diesel pump we can add a pump provision set up to the outside of the tank as shown below:

Includes:

• Lockable Metal Protection Box
• Nozzle
• Flow Meter and Filter

NOTE – PUMP NOT INCLUDED

TANK DELIVERY INFORMATION

As the 10000 Litre Tank are approximately 350kg. We suggest you have lifting equipment on hand on day of delivery. Delivery is at the driver’s discretion – if they feel it’s safe and there is plenty of room for a 16m truck and trailer to turnaround they will attempt to deliver close to the tank pad as possible. If not, they will deliver to front of site.  Please note drivers will not lift tanks due to OH&S.

Minimum 2 Strong Adults are required on day of delivery to help driver.

Get Tanked Water Tanks are happy to chat with you about your water storage needs. If you would like more information please do not hesitate to contact us Contact Us
